Adapter | Type 2 male - Type 1
Code: 31204Product detailed description
Mode 3 adapter to connect charging station with connector Type 2 with a car that has a Type 1 connector. The cable has 6mm wires for charging with a maximum current of 32A / 7.4kW.
CAUTION: Does not work in conjunction with the Tesla WallBox, which is set by default. Legacy mode set up is needed.
Additional parameters
| Category: | Adapters |
|---|---|
| Weight: | 2 kg |
| Input plug type: | Type 2 | male |
| Output plug type: | Type 1 |
| Phase: | 1 phase |
| Rated max. current: | 32 A |
| Voltage: | 230 V |
| Rated power: | 3,7 - 7,4 kW |
| Housing: | IP54 |
| Cable length: | 0,5 meter |
| Working temperature: | - 40°C ~ + 75°C |
| Cable: | 3x6,00mm2 + 1x0,75mm2 |
| Usage: | Inner / Outdoor |
